Muncie SM465 | Borg Warner T18 | Borg Warner T19 Five Speed TransmissionsĪisin Warner AX5 | Aisin Warner AX15 | Borg Warner T5 | Peugeot BA10 (AX18)
#NEW PROCESS 542 TRANSMISSION PARTS DIAGRAM SERIES#
T170 Series | New Process A833 | New Process 435 Id tags are mounted on the left side of the main case.Domestic Truck Transmission Identification Guide by Mike Weinberg, President, Rockland Standard Gear Inc. An easy way to identify this unit is by the cooling lines mounted to the case as found in automatic transmissions. A unique feature of this unit is an internal oil pump driven off the front of the countershaft that circulates the lube to a trans cooler. The S650 is found behind diesel engines of 1998 and up Ford Super duty and stripped chassis up to a gross combined weight of 26,000 lbs. This unit is built in both 2 and 4WD versions. This unit has an aluminum case with integral bell housing, a center support, and rear case. Great care should be taken to properly identify the unit you are working on as both the S542 and S547 appear to be the same and with the great variety of ratios available, it is easy to order the wrong parts.Īn extremely heavy-duty unit with 6 forward speed.
#NEW PROCESS 542 TRANSMISSION PARTS DIAGRAM SERIAL#
On the left side of the case is mounted and ID tag, which gives the Ford Part number, the ZF part number and the unit serial number. Both units have PTO covers on each side of case. The S547 unit is used behind the same engines from 1995 to present.
Great care should be taken to properly identify the unit you are working on as both the S542 and S547 appear to be the same and with the great variety of ratios available, it is easy to order the wrong parts. The S542 is found behind 300, 302, 351, 460, and diesel power plants. The Super duty model has a mechanical park brake assembly mounted to the extension housing. This unit is used in Ford F250, F30, F450, and Super duty trucks from 1987-94. Shifter is mounted to small shift cover on top of unit. The bell housing is integral to the case. The S 542 Heavy duty 5 speed fully synchronized transmission with aluminum case and extension housing. The case is very similar to earlier style units with case length shorter on 4.6L and 4.2L models. In 1999 the case was changed for 4.2L 4wd drive vehicles. In 1996 case is changed to accommodate modular motor (4.6L), with starter bolt pattern being triangular. 1995 and later models have top cover reverse light switch moved to forward corner of shift cover. Very similar in design to M5R1, but larger with shift lever located in center of shift cover.
Aluminum case, extension housing, and shift cover, with integral bell housing.
#NEW PROCESS 542 TRANSMISSION PARTS DIAGRAM FULL SIZE#
Mazda built 5 speed fully synchronized transmission found in 1988 to present Ford F150 series trucks and full size Broncos. Found in Ford F100-250 light duty trucks from 1984-85, also known as a TOD (top shift overdrive) Produced in 2 and 4 wheel drive versions. Top loaded 4 speed with 4th being overdrive. Produced in 2 and 4 wheel drive versions. There is also a passenger car version of this unit with lighter duty bearings and gear ratios. Used in Ford light duty pickup trucks 1980-83. Synchronized in all forward speeds with 4th being overdrive. Has an aluminum case with shifter turret mounted on extension housing. Produced in 2 and 4 wheel drive versions.Īlso known as Single Rail Overdrive (SROD). This unit was produced for cars also but with lighter duty bearings and gear train.
Three shift rails mounted to the left side of case. Similar in appearance to the Ford top loader transmission but has overdrive 4th gear. Used in 1978-84 Ford light duty pickups and vans. Synchronized in all forward gears, with top loaded cast iron case. The T19 has a single step reverse idler gear while the T18 has a 2 step reverse idler. Easily confused with T18, but the T19 is synchronized in all forward speeds. Top loaded heavy-duty 4-speed transmission with cast iron case and shift cover. produced in both 2 and 4 wheel drive versions Found in 1963-85 Dodge trucks, 1964085 Ford pickup trucks and stripped chassis, 1964 to 72 GM trucks, and International Harvester and Navistar trucks from 1964-85. 2nd through 4th gears are synchronized with 1st and reverse using non synchronized sliding gear. Top loaded heavy-duty 4-speed transmission with cast iron case and extension housing and aluminum shift tower. Care should be used when ordering parts to make positive ID of unit. Easily confused with earlier BW T98 and T98A models. Synchronized in 2nd,3rd, and 4th, with 1st and reverse non-synchronized.
